DWP44 is an excellent quality Dante interface box for converting four Dante channels to Analogue Audio outputs, and four Analogue Audio inputs to Dante network. DWP44 designed to fit with US style double-gang back box.
Simply use Cat5 cable to connect the RJ45 port to an Ethernet switch, and using “Dante controller” to route the low latency of signal to/from other devices which already connected on the same Dante network.
Dante Interface Mic/ Line 4 Inputs xLine 4
Outputs Features
1. TwoMic/Line XLR Inputs and One Mini-jackInput on Front Panel
2. Terminal Block for Two Audio Outputs on Rear Panel
3. One Mini-jack Output on Front Panel
4. ConvertsMic or Line Audio Signals to Dante Network
5. Mic or Line is Selectable for Each XLR Input
6. Switchable 48V Phantom Power for Each Mic XLR Input
7. Adjustable Mic/LIne Gain from -20 dB to+20dB for Each Input Channel
8. Stereo/Mono switch for Mini-jack Input and Output
9. Four Audio Signal Outputs from Dante Network
10. Balanced or Unbalanced Signal Outputs
11. High Resolution 24 Bit for DAC and ADC
12. LEDs Indicate the Status for Power and Network Sync on Front Panel
13. Power over Ethernet (PoE) or 24VDC power supply
14. Provides High Quality of Preamplifier for Microphones
15. Excellent Audio quality with low noise
